Third-party network cameras supported
• Up to 12 Megapixels resolution recording
• Video outputs at up to 4K (4096*2160) resolution
•Supports decoding up to 20 channels at 1080P resolution
• Up to 128/256 IP cameras can be connected with
512M/768M incoming bandwidth
• Up to 24 SATA interfaces
• Supports H.264+,H.264,MPEG4,H.265,MJPEG video format
• Support redundant power supply to improve the system
stability
• Support HDD hot swap with RAID0,1,5,6,10 storage
scheme configurable
•Support various VCA detection alarm and VCA search
| Video/Audio Input |
| IP video input: |
| |
128-ch |
| Two-way audio input: |
| |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network |
| Incoming bandwidth: |
| |
768Mbps |
| Outgoing bandwidth: |
| |
512Mbps |
| Remote connection: |
| |
256 |
| Video/Audio Output |
| HDMI Output: |
| |
2-ch, resolution: 4K(4096*2160)/60Hz, 4K(3840*2160)/30Hz, 2K(2560*1440)/60HZ, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
| Recording Resolution: |
| |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Audio Output: |
| |
1-ch, RCA (2.0Vp-p, 1KΩ) |
| VGA Output: |
| |
1-ch, resolution: 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
| Decoding |
| Live view / Playback: |
| |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability: |
| |
20+48 ch @1080P |
| Hard Disk |
| SATA: |
| |
16 SATA interfaces for 16 HDDs |
| miniSAS (Optional): |
| |
2 miniSAS interface |
| eSATA: |
| |
1 eSATA interface |
| Capacity: |
| |
Up to 8TB capacity for each HDD |
| Disk array |
| Array type: |
| |
RAID0, RAID1, RAID5, RAID6, RAID10 |
| Number of array: |
| |
8 |
| External Interface |
| Optic fiber interface: |
| |
4 1000 Mbps optional optic fiber interfaces |
| Network Interface: |
| |
4 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces |
| Serial Interface: |
| |
RS-232, RS-485, Keyboard |
| USB Interface: |
| |
Front panel: 2 × USB 2.0
Rear panel: 2 × USB 3.0 |
| Alarm In: |
| |
16-ch |
| Alarm Out: |
| |
4-ch |
| General |
| Power Supply: |
| |
100-240 VAC, 550W |
| Consumption(without hard disk and POE): |
| |
≤ 140W |
| Working Temperature: |
| |
0 ºC ~ +50 ºC (32ºF ~ 122ºF) |
| Working Humidity: |
| |
10 % ~ 90 % |
| Chassis: |
| |
3U chassis |
| Dimensions: |
| |
442 × 494 146 mm (17.4 × 19.4 5.7 inch) |
| Weight(without HDD): |
| |
≤16kg (35.3lb) |
